Application of Expanded metal mesh
Expanded Metal Fencing
Expanded metal mesh for fence
| Fence height |
1.8m |
2.1m |
2.4m |
| Heavy type |
Medium |
Heavy type |
Medium |
Heavy type |
Medium |
| Post size & type |
60.3 CHS |
| Overall post height |
2425mm (600 buried) |
2875mm (680 buried) |
3175mm (750 buried) |
| Post centre |
3000mm |
| Aperture |
102*51mm |
| Thickness |
3mm |
| Strand width |
5.0mm |
3.5mm |
5.0mm |
3.5mm |
5.0mm |
3.5mm |
| Panel size |
1830 x 3150mm |
2140 x 3150mm |
2440 x 3150mm |
| Number of horizontal rails |
2N° optional extra 3N° |
EXPANDED METAL FENCING Features
3 meter centers
Unique post stringer design
Designed to help facilities managers and security professionals deter unwarranted access, delay attack and detect potential problems before they arise
Available in a variety of diamond size openings and mesh plus gauges that can be specifically cut to meet your requirements
Standard heights up to 12 ft., additional heights available
Galvanized or powder coated, custom colors
Panels and fittings available to attach mesh to round or roll formed fence framework
Benefits:
Good through vision
Ease of installation
Low maintenance (Long life expectancy)
Difficult to penetrate and scale
Aesthetically pleasing
Medium to high security system
No protruding dangerous bolts
Police Preferred Specification
Mesh panels available in carbon steel or aluminum
Competitively priced
Anti-cut, anti-climb
